Product Description
The 2088-313-145 is the larger automatic spray pump with an open flow rate of 13.6 L/Min (at zero pressure). Viton and santoprene materials inside make it the ideal pump for most ag chemicals. A flow rate of 8.1 L/Min at 40 psi, 9.4 L/Min at 30 psi, and 10.7 L/min at 20 psi make it a good pump for larger flow nozzles. 12v DC with a maximum Amps draw of 10 Amps, needs a 15 Amp fuse. Positive displacement 3 chamber pump with a suction lift of up to 8 feet, the higher the suction lift, the less pressure and flow you get out of the pressure end. 1/2" male BSP inlet and outlets must be fitted with 1 x 1/2" barbed straight connector and 1 x 1/2" barbed elbow connector. Suitable for continuous use if ambient temperature is below 20C and the pump is in the shade. This pump is fitted with aluminium cooling fins for a longer working time. Maximum liquid temperature is 77 degrees C. Click here for adaptors.
CLICK HERE FOR THE SPEC SHEET WITH FLOWS AND PRESSURES
- 13.6 litres / minute maximum flow
- 2.8 bar maximum pressure
- Santoprene diaphragm
- Viton Check valve
- On demand pressure switch
- Built in check valve prevents back flow,
- fin cooled motor for continuous use.
- 1/2 inch male ports
- 10 amp draw requires 15 Amp fuse,
- Self-Priming up to 3.7 metres
